Why Are Honeycomb Cells Hexagonal?

Why Are Honeycomb Cells Hexagonal?

Grade Level

3 - 5

minutes

1- 2 hrs

subject

Mathematics

Activity Type:

, , , ,

Honeybees have evolved over time to skillfully build hexagonal honeycomb cells. Why might a hexagon be a suitable shape for storing honey? Could other shapes, such as circles, triangles, or squares, work just as well?

Let’s investigate this question by first making some observations of a honeycomb. We’ll take a macro, or wide, perspective so we can study the honeycomb’s overall appearance. Then we’ll zoom in for a micro, or close-up, perspective in order to observe specific details.

From a macro perspective, what do you observe about the shape of honeycomb cells?

Shutterstock

From afar, the cells might appear circular, as if they’re built to fit the elongated shape of a honeybee’s body.

Now let’s take a micro view and zero in on the cells.

From a micro perspective, what new details about the honeycomb cells did you observe?

Shutterstock

Did you notice the hexagonal shape of the cells?

Scientists use their observations to make sense of the world we live in. When scientists come across a phenomenon and are puzzled by what they observe, such as the hexagonal shape of a honeycomb cell, they will often ask questions and try to understand the phenomenon by forming a “claim.”

You have made several observations of honeycomb cells. Let’s form a claim about the shape of those cells.

A scientific claim . . .

  • answers a scientific question or problem and is usually a statement about, or understanding of, a phenomenon.
  • is always supported by scientific data or “evidence.”
  • provides “reasoning,” or a justification, that logically connects the evidence to the claim. It is usually based on a scientific definition, law, rule, or principle.
  • can be revised as more evidence is gathered and/or logical connections are made that support changes in reasoning.
Created by Xochitl Garcia

We often call the process of developing and explaining a claim “CER,” for Claim, Evidence, and Reasoning.

Why do honeybees use hexagonal shapes to construct their honeycombs?

Drawing from your observations of the honeycomb, use the CER worksheet to make a claim about why you think that the cells are shaped like hexagons.

See the Educator’s Toolbox for student worksheets and educator resources.

Honeycombs are made from beeswax, a substance created by worker bees. When the temperature is right, worker bees secrete wax scales from special glands in their body. Then they chew the wax with a bit of honey and pollen to produce the beeswax. The hexagonal cells serve as storage vessels for honey, as well as homes to raise young bees.

Bees secrete wax from special glands in their abdomens. Illustration by Corlette Douglas

Bees must build their honeycomb efficiently.

Illustration by Corlette Douglas

Bees collect nectar and pollen from flowers to make honey, a sugary food, for the colony. Honey provides bees with the energy they need to survive and reproduce, as well as to build their homes. In order to make enough wax, worker bees need a lot of energy, and must therefore consume a lot of honey. Some studies estimate that bees must consume eight ounces of honey for every ounce of wax they produce. Imagine how many flowers a bee must visit to be able to convert nectar into eight ounces of honey!

On average, each bee can produce about 1/12 of a teaspoon of honey in its lifetime. If a bee were to provide one pound of honey, it would need to visit about 2 million flowers. A whole colony may travel about 55,000 miles in its lifetime!

hardworking bee
Illustration by Corlette Douglas

Producing wax is hard work.

What would the proportion of honey consumed to wax produced look like? Measure water in a graduated cylinder (30 ml = 1 oz) to visualize the ratio.

  • Measure out 8 oz of “honey” (water colored to look like honey).
  • Measure out 1 oz of “wax” (regular water).

Compare the amount of honey and wax.

Photo by Stacy George

When building a honeycomb, bees must make sure they don’t waste more resources (wax) or expend more energy (honey) than necessary. This means that they need to use the least amount of wax possible to construct a comb that can store as much honey as possible.

Let’s investigate how different cell shapes might affect the amount of wax and space used to build a honeycomb.

You will conduct four investigations into how different types of shapes might affect the amount of wax and space needed to build cells in a honeycomb. Investigations should be conducted in sequential order, because each one builds upon previous investigations.

  • Honeycomb Cell Shape Investigation
  • Sharing Cell Walls Investigation
  • Investigating Surface Area of Cell Shapes
  • Investigating Volume of Cell Shapes

Honeycomb Cell Shape Investigation

Let’s imagine for a minute that we are worker bees. What would the honeycomb look like if the cells were different shapes? Using pennies and pattern blocks, or shapes cut from this template, you will experiment with different geometric shapes to see how well they would work as honeycomb cells. Try to arrange as many shapes together as possible with the least amount of wasted space. Remember, honeycomb cells are never a mixture of multiple shapes, so you can only use one shape at a time.

  • Materials

    — Pennies or circular candies (M&M’s, Skittles, or Bottle Caps)

    — Pattern blocks (square, triangle, and hexagon) or shapes cut from the pattern template

    Honeycomb Cell Shape Investigation Worksheet

    Let’s start with circle shapes, using pennies or candies.

  • Step 1

    Explore how multiple pieces of the shape fit together using the work mat on your Honeycomb Cell Shape Investigation Worksheet. You can arrange the shapes in any pattern, but make sure they are close to one another; leave as few gaps as possible between each shape. Try to stay within the boundaries of the mat, but it is okay if a part of the shape sticks outside.

  • Step 2

    Draw what you observe in the box provided on your Honeycomb Cell Shape Investigation Worksheet.

    Your drawing might show fewer shapes than you arranged on your mat. That’s okay! Just do your best to make your drawing reflect the pattern you arranged.

  • Step 3

    Shade in any empty space between the shapes you drew.

    Think about the following:
    — If bees were to construct honeycomb cells using this shape, what do you suppose they would place in the spaces between the shapes?
    — Is there a way to change the positioning of the shapes so that there is less space between them?

  • Step 4

    On your worksheet, write down detailed observations about the shape you just tried.

    Observations could include the following: How do the shapes fit together? What patterns do you see forming?

  • Step 5

    Repeat steps 1–4 with squares, triangles, and hexagons. Continue to record any patterns that emerge as you investigate.

Thinking about the investigation:

  • Based on your results, which shape appeared to be the worst shape for a honeycomb cell? Why?
  • Shapes can be arranged to form other shapes. As you experimented with each type of shape, did you form any new ones?

Revisit the claim you wrote on your CER Worksheet. Is there new evidence that you could add to your CER? Are there any changes you would make to the claim based on your investigation?

Sharing Cell Walls Investigation

How can you collect mathematical evidence to support or revise your claim?

Illustration by Corlette Douglas

You may have noticed from the previous investigation that arranging circles resulted in big gaps between each shape. If honeycomb consisted of circles, there would be a lot of wasted space between cells, and a worker bee would probably have to expend a lot of energy filling in those gaps with wax.

Diagram by Xochitl Garcia

Other shapes can be more tightly arranged. There are three shapes you tested that can be organized so that no gaps appear between them: equilateral triangles, squares, and hexagons. The reason these shapes pack so well is because they have straight edges that line up against each other. In other words, these shapes can be positioned to share walls.

Let’s explore how well different shapes that share walls would work as honeycomb cells. Using different colored markers and the Sharing Cell Walls Worksheet, you will investigate which shape can be used to build a honeycomb with the greatest number of shared cell walls. Note that you’ll be covering an area with the same dimensions for each shape you investigate.

Materials

Do this activity in a group of three, so each person can work on one shape (triangle, square, hexagon)!

  • Step 1

    Starting with the square shape, outline the first cell using a colored marker. How many cell walls did you outline?

    Record the number of cell walls in the middle of the cell.

  • Step 2

    Using a different colored marker, outline the next cell. Do not outline any cell walls that you colored in step 1. You’ll notice that there is one fewer wall that you have to outline.

    Record the number of cell walls you just outlined in the middle of that cell.

  • Step 3

    Continue outlining and counting cell walls until the first row is complete. (Remember to use alternating colors, and each wall should only be outlined once.)

    Add up the number of cell walls you outlined to complete the first row, and record that number at the end of the row.*
    *For the hexagon, do not record row totals. See step 4.

  • Step 4

    Continue outlining and counting cell walls in subsequent rows until the entire honeycomb is complete.*

    *For the hexagon, add up the number of cell walls you outlined to complete each column, and record those numbers in the boxes provided.

  • Step 5

    Add up the cell wall numbers from each row (or column), and record the grand total number of cell walls at the bottom of the worksheet.

  • Step 6

    If you are working independently, repeat steps 1–5 with each remaining shape (triangle and hexagon).

Thinking about the investigation:

Compare your data for each shape.

  • Which shape required you to outline the most cell walls?
  • Which shape required you to outline the fewest cell walls?

Did quantifying your data change or support your original claim about why bees might use hexagons to build their honeycomb cells? Add to (or revise) your original claim on your CER Worksheet.

Investigating Surface Area Of Cell Shapes

By building honeycomb cells that share walls, bees can better conserve their resources (wax) and energy (honey). But don’t forget that bees use the combs as storage vessels for their honey. When bees construct their combs, they need to minimize the space between cells while maximizing the space available within the cell to store their honey.

Materials

●      Exploring Surface Area and Volume of Cell Shapes Worksheet

●      Working copy of CER Worksheet

  • Find the surface area of each shape.

    Using the surface area formulas on the Exploring Surface Area and Volume of Cell Shapes Worksheet, calculate the area of a square with two-inch sides. Then calculate the area of a triangle if its base and height are each two inches long. Is there a difference in the surface area of the two shapes?

  • Now, calculate the area of a hexagon.

    Reference the observations you made during the Honeycomb Cell Shape Investigation. As you perhaps noticed, six triangles can be arranged into a hexagon. Calculate the area of a hexagon if each triangle has a two-inch base and a two-inch height. Record your formula and data for surface area on the worksheet.

Thinking about the investigation:

  • Which shape had the greatest surface area?
  • How could a honeycomb cell with a large surface area benefit a bee?

Revisit your CER Worksheet and continue to add to (or revise) your claim and/or evidence.

Investigating Volume Of Cell Shapes

From the area investigation above, you should have found that the hexagon had the greatest surface area of the shapes you tested. Now let’s explore the volume of different shapes. We will use cell-shaped prisms to help us with this investigation.

Triangular Prism Template

Materials

  • Step 1

    Cut out the square prism pattern and the triangular prism pattern from the template. These will serve as 3D models of cells.

  • Step 2

    Fold each template along the dotted “fold” line, and secure the sides with tape.

  • Step 3

    Tape over one end of each cell so it’s completely covered. You will be pouring sand into the other end and don’t want any to escape.

  • Step 4

    Pour sand into the cells until you reach the top.

    Quick tip: Use recycled paper coffee cups with travel lids to pour sand into cells.

  • Step 5

    Measure the volume of sand you poured into one cell by transferring the sand into a graduated cylinder. Then record your measurements on the Exploring Surface Area and Volume of Cell Shapes Worksheet. Repeat for the second cell.

  • Step 6

    Find the volume of a hexagon cell using your data from step 5. Record your finding on the worksheet.

    Hint: Six triangles form a hexagon.

Thinking about the investigation:

Compare the volume of all your shapes. Which shape would store the most amount of honey?

Revisit your CER Worksheet and continue to add to (or revise) your claim and/or evidence.

Assessment — Revisiting And Revising Your Claim Statement

Revisit the original question at the beginning of this lesson:

Why do honeybees use hexagonal shapes to construct their honeycombs?

Reflect on your findings from the four investigations.

  • Which shape was associated with the fewest spaces between shapes?
  • Which shape was associated with the most shared walls?
  • Which shape had the greatest surface area?
  • Which shape had the greatest volume?

Use the Claim-Evidence-Reasoning (C-E-R) method to revise or add to the claim on your worksheet. Be sure to include data based on your findings from the four different investigations.

  • In the Honeycomb Cell Shape Investigation, what evidence did you gather that helped you revise or support your claim?
  • What evidence did you gather from the Sharing Cell Walls Investigation that helped you revise or support your claim?
  • What evidence did you gather from the Investigating Surface Area of Shapes activity that helped you revise or support your claim?
  • What evidence from the Investigating Volume of Shapes exercise helped you revise or support your claim?

The Honeycomb Conjecture

In ancient times, a Roman scholar named Marcus Terentius Varro studied his collection of bees and proposed that the hexagonal structures that honeybees build are more compact than any other shape. But it was thousands of years later—in 1999, in fact—that a mathematician at the University of Michigan named Thomas Hales was able to provide mathematical proof of what is known as the “Honeycomb Conjecture.” Hales concluded that the more compact the shape of the honeycomb cell was, the less energy and wax a bee would use to build it, which meant that bees could expend their energy on other important activities—specifically, foraging and making honey.

Learn more about how Thomas Hale solved the hexagonal honeycomb mystery in this short BBC video.

Extensions

Would you like to experience what it’s like inside a beehive? Take a look at the Science Friday article Step Into a Hive, by Chau Tu, to see how sculptor Wolfgang Buttress created the experience of being inside a beehive.

The Hive. Credit: Jeff Eden
  • After reading “Step Into a Hive,” explore how bees are able to communicate.
  • Explore bubbles as they connect to form hexagons.

Additional Video Resources

Next Generation Science Standards

Common Core State Standards: Standards of Mathematical Practice

  • SMP 3:  Construct viable arguments and critique the reasoning of others
  • SMP 4:  Model with mathematics
  • SMP 7:  Look for and make use of structure
  • SMP 8: Look for and express regularity in repeated reasoning

Teachers who field tested this resource had the following advice for teachers adopting this resource:
Betsy from Kansas said:I loved how the students were able to use the evidence from each of the investigations to support the claim as to why honeybees use the hexagon. I also loved the questions that students were having based on the investigations. I had one student ask if wasps were similar to the honeybee in how they love and create their homes.


Rose from Georgia said: I supplemented “activators” by having some bee trivia facts to each opening session. Incentives included “busy as a bee” badges and small treats to keep the hive Bzzzzy! The best part was the hands-on activities that allowed true connection to the content. The conclusions were easy to determine at the student level with the completed activity sheets.
